380 - 385MHz Tetra Wide Band Cell Signal Repeater For Mobile Phone , Indoor Use

    Buy cheap 380 - 385MHz Tetra Wide Band Cell Signal Repeater For Mobile Phone , Indoor Use from wholesalers

    Buy cheap 380 - 385MHz Tetra Wide Band Cell Signal Repeater For Mobile Phone , Indoor Use from wholesalers
    • Buy cheap 380 - 385MHz Tetra Wide Band Cell Signal Repeater For Mobile Phone , Indoor Use from wholesalers
    • Buy cheap 380 - 385MHz Tetra Wide Band Cell Signal Repeater For Mobile Phone , Indoor Use from wholesalers
    • Buy cheap 380 - 385MHz Tetra Wide Band Cell Signal Repeater For Mobile Phone , Indoor Use from wholesalers
    • Buy cheap 380 - 385MHz Tetra Wide Band Cell Signal Repeater For Mobile Phone , Indoor Use from wholesalers
    • Buy cheap 380 - 385MHz Tetra Wide Band Cell Signal Repeater For Mobile Phone , Indoor Use from wholesalers
    • Buy cheap 380 - 385MHz Tetra Wide Band Cell Signal Repeater For Mobile Phone , Indoor Use from wholesalers

    380 - 385MHz Tetra Wide Band Cell Signal Repeater For Mobile Phone , Indoor Use

    Ask Lasest Price
    Brand Name : GREETWIN
    Model Number : GW-20T
    Certification : SGS, ISO9001
    Price : Negotiable
    Payment Terms : T/T, L/C
    Supply Ability : 5000pcs per Month
    Delivery Time : 10 Working Days After Received Payment
    • Product Details
    • Company Profile

    380 - 385MHz Tetra Wide Band Cell Signal Repeater For Mobile Phone , Indoor Use


    380 - 385MHz Tetra Wide Band Cell Signal Repeater For Mobile Phone , Indoor Use

    380 - 385MHz Signal Repeater Description:


    Greetwin has one of the most experienced TETRA engineering and design capabilities in the industry and are regularly called upon by network operators, public safety systems integrators, base station manufacturers and public safety authorities to help solve a TETRA coverage issue.


    Indoor Signal Booster series is an ideal solution for small/medium businesses and home users looking to enhance indoor wireless connectivity. It is connected via coaxial cable to Donor Antenna and Service Antenna, Donor Antenna is placed outside the building where it has easy access to a BTS signal, and the Service Antenna is placed in the building where it can extend radio coverage to the blind area.


    380 - 385MHz Signal Repeater Standard Package:
    1) AC90-264V, power supply adapter 1PCS
    2) AC power cord (EU/US/UK/SA/China standard, etc) 1PCS
    3) Installation kit 1PCS
    4) User manual 1PCS


    380 - 385MHz Signal Repeater Recommended Accessories:
    1)Donor antenna: Log Periodic Antenna (11dBi,806-960/1710-2700MHz)
    2)Service antenna: Omni Ceiling Antenna (3dBi,806-960/1710-2700MHz)
    3)5D-FB coaxial cable with connecter (Cable length optional)


    380 - 385MHz Signal Repeater Features:

    1. Cost effective solution for weak signal zones,
    2. Compact size, low power consumption, easy installation, great cover.

    Expansion and extention of the signal of base station.

    Optimization of the quality of the signal and source
    3. Cover about 500~1500 m² without block or obstruct.
    4. High linear design, ALC function design, low interference to BTS.
    5. Support any cellular devices (voice & data & video)
    6. Wide band signal booster, or customize selective band booster.


    380 - 385MHz Signal Repeater Application:
    To expand signal coverage of fill signal blind area where signal is weak or unavailable.

    Indoor: Hotels, Home, Basements, Shopping Malls, Offices, Parking Lots, etc.


    380 - 385MHz Signal Repeater Specification:


    Frequency RangeUplinkDownlink
    Tetra 400380 - 385MHz390 - 395MHz
    Max. Gain65dB70dB
    Max. Output Power17dBm20dBm
    Band widthWide Band
    Manual Gain Control15dB / 1dB Step
    Automatic Gain Control>25dB
    Ripple in-band≤ 6dB
    Return loss≤ -10dB
    Noise Figure≤ 6dB
    Spurious Emission9KHz~1GHz≤ -36dBm
    1~12.75GHz≤ -30dBm
    Third-Order Intermodulation≤ -40dBc
    Time Delay≤ 1.5 μs
    Frequency stability≤ 0.01ppm
    MTBF> 50000 hours
    Power SupplyAC100-240V
    Power LEDPower indicator
    Alarm LEDGreenStandard
    RedSelf-oscillation or High Power
    Mechanical Specification
    RF ConnectorN-Female
    SwitchPower Switch
    CoolingHeatsink Convection cooling
    Impedance50 ohm
    Humidity< 90%
    Operating Temperature-20°C ~ +55°C
    Environment ConditionsIP40
    Size360mm*265mm*100mm
    Weight< 0.8 Kg
