    395MHz Tetra Repeater , 390MHz Mobile Signal Repeater with 20dBm Output Power

    Ask Lasest Price
    Brand Name : GREETWIN
    Model Number : GW-20T
    Certification : SGS, ISO9001
    Price : Negotiable
    Payment Terms : T/T, L/C
    Supply Ability : 5000pcs per Month
    Delivery Time : 10 Working Days After Received Payment
    • Product Details
    • Company Profile

    395MHz Tetra Repeater , 390MHz Mobile Signal Repeater with 20dBm Output Power

    390 - 395MHz Tetra Repeater , Mobile Signal Repeater with 20dBm Power

    390MHz Mobile Signal Repeater Description:


    Greetwin TETRA and TETRAPOL products fully cover both bands and can be used to provide coverage by themselves or as a feeder into a DAS (Distributed Antenna System). Being software based new features and capabilities can be easily installed in the future such as support for TEDS (TETRA Enhanced Data Services).


    Indoor Signal Booster series is an ideal solution for small/medium businesses and home users looking to enhance indoor wireless connectivity. It is connected via coaxial cable to Donor Antenna and Service Antenna, Donor Antenna is placed outside the building where it has easy access to a BTS signal, and the Service Antenna is placed in the building where it can extend radio coverage to the blind area.


    390MHz Mobile Signal Repeater Standard Package:
    1) AC90-264V, power supply adapter 1PCS
    2) AC power cord (EU/US/UK/SA/China standard, etc) 1PCS
    3) Installation kit 1PCS
    4) User manual 1PCS


    390MHz Mobile Signal Repeater Recommended Accessories:
    1)Donor antenna: Log Periodic Antenna (11dBi,806-960/1710-2700MHz)
    2)Service antenna: Omni Ceiling Antenna (3dBi,806-960/1710-2700MHz)
    3)5D-FB coaxial cable with connecter (Cable length optional)


    390MHz Mobile Signal Repeater Features:

    1. Cost effective solution for weak signal zones,
    2. Compact size, low power consumption, easy installation, great cover.

    Expansion and extention of the signal of base station.

    Optimization of the quality of the signal and source
    3. Cover about 500~1500 m² without block or obstruct.
    4. High linear design, ALC function design, low interference to BTS.
    5. Support any cellular devices (voice & data & video)
    6. Wide band signal booster, or customize selective band booster.


    390MHz Mobile Signal Repeater Application:
    To expand signal coverage of fill signal blind area where signal is weak or unavailable.

    Indoor: Hotels, Home, Basements, Shopping Malls, Offices, Parking Lots, etc.


    390MHz Mobile Signal Repeater Specification:


    Frequency RangeUplinkDownlink
    Tetra 400380 - 385MHz390 - 395MHz
    Max. Gain65dB70dB
    Max. Output Power17dBm20dBm
    Band widthWide Band
    Manual Gain Control15dB / 1dB Step
    Automatic Gain Control>25dB
    Ripple in-band≤ 6dB
    Return loss≤ -10dB
    Noise Figure≤ 6dB
    Spurious Emission9KHz~1GHz≤ -36dBm
    1~12.75GHz≤ -30dBm
    Third-Order Intermodulation≤ -40dBc
    Time Delay≤ 1.5 μs
    Frequency stability≤ 0.01ppm
    MTBF> 50000 hours
    Power SupplyAC100-240V
    Power LEDPower indicator
    Alarm LEDGreenStandard
    RedSelf-oscillation or High Power
    Mechanical Specification
    RF ConnectorN-Female
    SwitchPower Switch
    CoolingHeatsink Convection cooling
    Impedance50 ohm
    Humidity< 90%
    Operating Temperature-20°C ~ +55°C
    Environment ConditionsIP40
    Size360mm*265mm*100mm
    Weight< 0.8 Kg
