    4G Wirelss 150W 400MHz RF BDA Mobile Signal Repeater

    Ask Lasest Price
    Brand Name : GREETWIN
    Model Number : GW-36T
    Certification : SGS, ISO9001
    Price : $2123.1-2412.6
    Payment Terms : T/T, L/C
    Supply Ability : 10000
    Delivery Time : 3-5days
    • Product Details
    • Company Profile

    4G Wirelss 150W 400MHz RF BDA Mobile Signal Repeater

    Outdoor Indoor TETRA 400 MHz bands Channel Selective RF BDA Bi Directional Amplifier Phone Signal Booster


    The BDA is working as a relay between the BTS and mobiles. It receives the low-power signal from BTS via the Donor Antenna, linearly amplifies the signal and then retransmits it via the Coverage Antenna to the weak/blind coverage area. And the mobile signal is also amplified and retransmitted to the BTS via the opposite direction.


    ItemSpecifications
    Frequency RangeUplink410-415MHz
    Downlink420~425MHz
    Maximum Input Power (Non-Destructive)0dBm
    Maximum GainUplink85±3dB
    Downlink90±3dB
    Maximum Output PowerUplink30±2dBm
    Downlink36±2dBm
    Gain Adjustment Range1~31 dB @ step of 1 dB
    AGC Range≥20dB
    VSWR≤1.5
    Noise Figure≤ 6dB
    In-band Ripple≤±2.5dB
    Spurious Emission9kHz~1GHz: ≤ -36dBm
    1GHz~12.75GHz: ≤ -30dBm
    Third-order Inter-Modulation≤ -45dBc
    System Delay≤8μSec
    I/O Impedance50Ω
    RF ConnectorN- Female
    Temperature RangeOperation: -25°C ~ + 55°C
    Relative Humidity Range≤ 95% (Non Condensing)
    Power SupplyAC220V,50/60Hz
    Power Consumption≤150W
    ApplicationIndoor and outdoor (IP65)
    Dimensions428mm X 328mm X175mm
    Weight≤15kg
    Local ControlPC+USB and WiFi Hotspot
    Remote Monitoring(Optional)4G Wirelss Modem(Cloud Network Management System)
    NMS Monitoring Function

    Real-time alarm for door status, temperature, power supply, VSWR, etc;

    Remote control such as turn on/off, increasing/decreasing output power etc;

    Real-time status for output/input power, UL/DL gain, all status of BDA etc.


    Features:

    • Aluminum-alloy casing with IP65 protection has high resistance to dust, water and corroding
    • Channel-selective function can amplify only the signals transmitted by the customized 2 channels
    • Adopting filter with highly selectivity and low insertion loss eliminates interference between uplink and downlink
    • USB port provides a link to a notebook for local supervision or IP Based NMS (Network Management System) that can remotely supervise BDA’s working status and download operational parameters to the BDA Via Ethernet or LAN

    OEM Customized Service
    Silkscreen OEM service can be offered


    To expand signal coverage or fill signal blind area where signal is weak or unavailable.

    Outdoor:Airports, tourism regions, golf courses, tunnels, factories, mining districts, villages, …
    Indoor:Hotels, exhibition centers, basements, shopping malls, offices, parking lots, …
